Smooth Rough Industrial Transmission Urethane Round Belt Polyurethane Cord Connected

Name: Smooth Rough Industrial Transmission Urethane Round Belt Polyurethane Cord Connected
Brand: Jiuna
Price: 1 USD

Brand Name : Jiuna

Model Number : PU Round Belt

Certification : ROHS

Place of Origin : China

MOQ : 500pics

Payment Terms : T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C

Supply Ability : 96.000 meters per Month

Delivery Time : Within 5 working days After receipt of your deposit

Packaging Details : Inner packing is plastic film .outer packing is carton

length : 400m/roll 200m/roll

hardness : 90 A

color : orange and green

material : PU

diameter : 2mm-20mm

Contact Now

Industrial Transmission urethane round belt Polyurethane Cord connected

Polyurethane raw materials have good oil resistance, corrosion resistance, solvent resistance, ozone resistance, aging resistance, environmental protection and non-toxic. Smooth round belt, V-belt surface finish is good, bright color, rough round belt surface rough, uniform particles, feel comfortable

PU Cord Properties :

-High tensile strength

-Excellent abrasion resistance

-Good resistance to fuel , oils and oxygen

-Contains no plasticizer

-Wide application temperature from -30℃~+80℃

Polyurethane cord Application

-Printing and folding machine

-Newspaper conveying

-Packing machine

-Ceramic and stone ware

-Processing, Plants, Canneries

-Conveying, Wood working machine

-Paper and Cardboard converting

-industry conveying line

Items NO.Φ	Least radius of gyration		Stretching rate	Maximum tensile rate		Hardness	Length of rolled
DIA(mm)	In	mm	%	Kg	Lbs	Shore( A)	Length of rolled
2mm	0.79	20	1.5-3%	0.3	0.7	95	400
2.5mm	0.87	22	1.5-3%	0.4	0.9	95	400
3mm	0.98	25	1.5-3%	0.7	1.6	90	400
3.5mm	1.18	30	1.5-3%	0.95	2.1	90	400
4mm	1.38	35	1.5-3%	1.2	2.7	90	200
5mm	1.57	40	1.5-3%	2.0	4.3	90	100
6mm	1.97	50	1.5-3%	3.2	7.0	90	100
7mm	2.17	55	1.5-3%	4.1	9.0	90	100
8mm	2.56	65	1.5-3%	5.0	11.0	90	100
9mm	2.95	75	1.5-3%	6.8	15.0	90	50
10mm	2.95	75	1.5-3%	7.7	17.0	90	50
12mm	3.94	100	1.5-3%	12.2	27.0	90	30
15mm	4.72	120	1.5-3%	17.7	39.0	90	30
18mm	5.71	145	1.5-3%	25.4	56.0	90	30
20mm	6.30	160	1.5-3%	31.3	69.0	90	30
